DVG-MES9019-013-BZ
ADS-TEC MES9000 Basis 18.5" Full-HD, PCAP Multi-Touch, Intel Celeron, 24V DC
| Manufacturer: | ads-tec |
|---|---|
| Manufacturer no.: | DVG-MES9019-013-BZ |
| Product no.: | S-021-155931 |
Available, Delivery time: 3 weeks
Product information
Description
MES9000 as an HMI panel PC impresses not only with its high performance and simple integration into the machine or system, but also with the outstanding user-friendliness of the large multi-touch display and the contemporary design.
Show more
Show less
Technical data
| Width: | 310 mm |
|---|---|
| Height: | 80 mm |
| Length: | 465 mm |
| Weight: | 6 kg |
| Ambient temperature max.: | 40 °C |
| Ambient temperature min.: | 0 °C |
| Analog interfaces: | 1 x DisplayPort++ (1.2), 1 x Smartcard-Reader für ADS-TEC Big-LinX |
| Brightness (cd/m²): | 500 |
| CPU: | Intel® Celeron® 4305UE 2,0 GHz |
| Country of origin: | Germany |
| Display size: | 18.5" |
| Ethernet interfaces: | 3 x Ethernet (10/100/1000 Mbit/s) |
| Height: | 80 mm |
| Input voltage: | 24 VDC |
| JMobile usable?: | No |
| Memory / Flash: | 128 GB |
| On/off switch: | Yes |
| Operating humidity (relative): | not specified |
| Operating system: | IGEL Linux, Windows 10 IoT Enterprise 2021 LTSC |
| Operating voltage (typical): | 0 V |
| Power consumption (W): | 0 W |
| Protection rating: | IP65 |
| RAM: | 8 GB |
| Resolution: | Not specified |
| Splinter protection: | No |
| Touchscreen: | PCAP Multi-Touch |
| USB interfaces: | 4 x USB 3.1 Gen. 2 |
| Voltage range max.: | 0 V |
| Voltage range min.: | 0 V |
