eX715MH Web
EXOR Web HMI 15.6" Full HD, PCAP, 3x Eth.
| Manufacturer: | Exor International S.p.A |
|---|---|
| Product no.: | S-061-158696 |
Available, Delivery time: 3 weeks
Produktinformationen
Description
Variants Properties
Technical data
| Height: | 267 mm |
|---|---|
| Length: | 422 mm |
| Weight: | 4.1 kg |
| Brightness (cd/m²): | 350 |
| CPU: | 64-bit RISC quad core - 1.6GHz |
| Country of Origin: | Italy |
| Depth: | 64 mm |
| Display size: | 15.6" |
| Ethernet interfaces: | 3 (1 x 10/100/1000, 2 x 10/100) |
| Height: | 267 mm |
| JMobile usable?: | No |
| Max. ambient temperature: | 70 °C |
| Memory / Flash: | 4000 MB |
| Min. ambient temperature: | -20 °C |
| Portection rating: | IP66 |
| RAM: | 2000 MB |
| Resolution: | 1920 x 1080 |
| Serial interfaces: | 1 (RS-232,RS-485,RS-422 MPI SW config) |
| Standards / Approvals: | ATEX Zone 2/22, CE, DNV-GL, IECEx Zone 2/22: Ex nA IIC T5 Gc, Ex tc IIIC T95°C Dc, RCM, UL61010-1, UL61010-2-201 |
| Touchscreen: | PCAP Multi-Touch |
| USB interfaces: | 2 (Host V2.0) |
Downloads
Accessories
More information
The eX715MH Web combines state-of-the-art connectivity features and top browsing performance in a great design. It is the ideal choice for all demanding IoT edge applications in factory, marine and building automation where a powerful and performing HTML5 web browser is needed.
The glass projected capacitive touchscreen and the brilliant 15.6-inch widescreen display with Full HD resolution (1920x1080 pixels) guarantee great optical performance. Supported by multitouch gesture programming, it allows for the creation of more natural human interfaces.
Technical Highlights:
- 15.6" TFT colour display with 1920x1080 pixel resolution
- Projected capacitive glass multitouch screen
- Chromium-based HTML5 browser supporting kiosk mode
- 3 Ethernet ports with full network separation
- Operating temperature range from -20 °C to +60 °C
- Certifications: IECEx, ATEX, DNV-GL, cULus Class 1 Div 2
The system is powered by a 64-bit RISC quad-core 1.6 GHz processor and runs on Linux. It supports Corvina Cloud secure connectivity and offers high integration flexibility through two expansion slots for plug-in modules.
