SCH16f

SCANCON SCH16f, encoder, Ø16mm, hollow shaft, max 3600PPR, IP50, 5–30VDC

Manufacturer:	SCANCON
Manufacturer no.:	SCH16F
Product no.:	S-008-158370

Available, Delivery time: on request

Contact sales

The product has been removed from the comparison list.

The product has been added to the comparison list.

There are too many products in the comparison list.

SCH16f has been added to the cart has been removed from the cart

Cart

Product information

Description

Compact incremental encoder SCANCON SCH16f with Ø16mm housing and Ø3mm or Ø4mm hollow shaft. Up to 3600 PPR, 5 or 5–30VDC supply, A, B, Z signals with TTL, RS422 or open collector. IP50, –20°C to +85°C. Snap-on flange mounting.

Show more Show less

Technical data

Weight:	0.015 kg
ATEX:	No
Ambient temperature max.:	70 °C
Ambient temperature min.:	-20 °C
Cable length:	1 m
Country of origin:	Denmark
Diameter:	16 mm
Encoder resolution max. (PPR):	5000
Encoder resolution min. (PPR):	100
Encoder type:	Incremental-Encoder
Protection rating:	IP50
Shaft diameter max.:	3.175 mm
Shaft diameter min.:	1.5 mm
