SCH120M
SCANCON SCH120M Heavy-Duty Encoder, Magnetic, IP66, Status LED
| Manufacturer: | SCANCON |
|---|---|
| Manufacturer no.: | SCH120M |
| Product no.: | S-008-158417 |
Available, Delivery time: on request
Product information
Description
The Scancon SCH120M was specifically developed for the heaviest industrial applications where reliability and robustness are paramount. Thanks to magnetic sensing and fully encapsulated electronics, it is the ideal choice for motors and drive applications in harsh environments.
Design: Compact heavy-duty body with 120 mm length
Diagnostics: Integrated status LED and alarm output for early fault detection (e.g., rotor misalignment)
Robustness: IP66 protection rating, shock resistant up to 100 G, and vibration resistant up to 10 G
Shaft Intake: Various hollow shaft options from 5/8 inch to 1 1/8 inch available
Safety: Built-in Transient Suppression Module (TSM) to protect against electrical interference
Show more
Show less
Technical data
| Weight: | 0.9 kg |
|---|---|
| ATEX: | No |
| Ambient temperature max.: | 105 °C |
| Ambient temperature min.: | -40 °C |
| Country of origin: | Denmark |
| Diameter: | 120 mm |
| Encoder resolution max. (PPR): | 8192 |
| Encoder resolution min. (PPR): | 1 |
| Encoder type: | Incremental-Encoder |
| Protection rating: | IP66 |
| Shaft diameter max.: | 25.57 mm |
| Shaft diameter min.: | 15.87 mm |
| Shaft length max.: | 0 mm |
| Shaft length min.: | 0 mm |
