eX207
EXOR eX207 WEB, 7", Multi-Touch, 1024x600, Linux, 2 GB RAM, 4 GB Flash
| Manufacturer: | Exor International S.p.A |
|---|---|
| Manufacturer no.: | 101006200U-0003 |
| Product no.: | S-061-156346 |
From stock
1 product in stock
Product information
Description
EXOR eX200 series: Technology at the service of the process
The new MMS of the EXOR eX200 series combine excellent technical specifications with high performance and integrate the CORVINA software and platform.
These MMS not only offer control and data visualisation functions, but also open the door to the IIoT world and provide easy access to innovations and technological advances.
They offer greater security to protect sensitive data and can be customised to meet specific requirements. Essentially, it is a strategic investment in operational efficiency.
Show more
Show less
Technical data
| Height: | 147 mm |
|---|---|
| Length: | 187 mm |
| Weight: | 1 kg |
| Ambient temperature max.: | 70 °C |
| Ambient temperature min.: | -30 °C |
| Brightness (cd/m²): | 500 |
| CPU: | 64-bit RISC quad core - 1.6GHz |
| Country of origin: | Italy |
| Depth: | 37.5 mm |
| Display size: | 7" |
| Ethernet interfaces: | 2 (2 x 10/100) |
| Height: | 147 mm |
| JMobile usable?: | Yes |
| Memory / Flash: | 4 GB |
| Operating system: | Linux |
| Operating voltage (typical): | 24 V |
| Protection rating: | IP66 (Front) / IP20 (Rear) |
| RAM: | 2 GB |
| Resolution: | 1024 x 600 |
| Standards / Approvals: | CE, UL61010-1, UL61010-2-201 |
| Touchscreen: | PCAP Multi-Touch |
| USB interfaces: | 1 (Host V2.0) |
| Voltage range max.: | 32 V |
| Voltage range min.: | 9 V |
Show more
Show less
Downloads
Show more
Show less
More information
EXOR eX200 series: Technology at the service of the process
The new MMS of the EXOR eX200 series combine excellent technical specifications with high performance and integrate the CORVINA software and platform.
These MMS not only offer control and data visualisation functions, but also open the door to the IIoT world and provide easy access to innovations and technological advances.
They offer greater security to protect sensitive data and can be customised to meet specific requirements. Essentially, it is a strategic investment in operational efficiency.
